Two Full Flow Clear Water Filter Housings for 10" x 4.5" cartridges are manufactured with durable FDA grade polypropylene with top quality, heavy-duty construction.
Flow Clear Water Filter Housing for 10" x 4.5" cartridges offers the versatility to meet all of your large-capacity filtration needs, including high-flow and heavy-sediment applications. The extra large housing allows for greater cartridge capacity, reducing the number of vessels required for high-flow rate applications.
Technical
Straight thread design on sump EPDM O-ring
Max Pressure: 90 psi (6.3 bar)
Max Temperature: 125°F
Service Flow Rate: up to 35 GPM @ 60 psi
Inlet/Outlet: 1"
Dimensions - Height: 14 " Width: 7-5 " (each)
Materials
Cap : Polypropylene
Sump: Styrene Acrylonitrile
Button Assembly 300 series stainless steel, EPDM, polypropylene
O-Ring: EPDM
