The HI-96813 is used across the wine industry for measuring the concentrations of sugars in wine.
This digital wine refractometer is rugged, lightweight and water resistant for measurements in the lab or field. Measures the refractive index and displays both % brix and potential alcohol in units of % V/V.
Priced inexpensively does not mean a compromise on accuracy, the Hanna refractometer offers all the benefits of high precision digital technology at the same price as a mechanical model.
The HI-96813 allows the user to tailor the instrument to their specific needs based on their experience, since no fixed conversion factor is universally applicable. The first conversion is based on the %Brix value and an adjustable conversion factor between 0.50 and 0.70 (0.55 is a common value).
Key features
White water resistant casing - IP65
Easy clean Stainless Steel sample well
Zero using pure water
Battery operated with auto shut-off
Ideal for use in wineries and vineyards
Main benefits
1.5 second measurement time
Direct readout
Automatic temperature compensation
No calibration solutions required
Large clear LCD display
{Technical}
Range - Sugar content 0 to 50 % Brix; 0.0-25.0 % V/V Potential Alcohol
Range - Temperature 0 to 80°C (32 to 176°F)
Resolution - Sugar Content ±0.1 % Brix;
±0.1 % V/V Potential Alcohol
Resolution - Temperature ±0.1°C (0.1°F)
Accuracy (@20°C) - sugar content ±0.1 °Baumé;
±0.2 V/V Potential Alcohol
Accuracy (@20°C) - Temperature ±0.3°C (0.5°F)
Temperature Compensation Automatic between 10 and 40°C (50 to 104°F)
Measurement Time Approximately 1.5 seconds
Minimum Sample Volume 100 µL (to cover prism totally)
Light Source Yellow LED
Sample Cell Stainless Steel ring and flint glass prism
Auto-off After 3 minutes of non-use
Enclosure Rating IP 65
Battery Type / Battery Life (1) 9V / Approx 5000 readings
Dimensions 192 x 102 x 67 mm (7.6 x 4 x 2.6”)
HI-4020-11 Brix standard 50%, 10mL
